M6 & M8 Rigifix Anchoring System
M6 & M8 Rigifix Anchoring System
The revolutionary rigifix® all-in-one dry lined wall fixing solution
See also: Rigifix Lite
After almost 20 months in research and development, their bespoke design team, in conjunction with a leading UK University have now achieved a product destined to be the fixing product of the year. Why? Because it’s creation is led by its potential application. The days of traditional plastering are over; we dry line with plasterboard/fibre board, which whilst economical and practical, raises issues for attaching contemporary heavy items such as plasma televisions, Boilers and designer radiators.
Suitable for:
Fixing heavy duty items e.g. TV/ PC/ Plasma screens, kitchen units, radiators, shelving, curtain poles, air conditioning units, etc. to a dry lined or fibre insulation board wall, transferring the load to the masonry without affecting the plasterboard integrity.
Application:
Drill hole to required diameter and depth, (see chart) and insert the plastic Rigifix©
expansion plug. Using an Allen key screw into the plug the threaded sleeve until the sleeve is fully home, or to the level of the plug head. Place the Pozi headed set screw through your bracket/item and screw down into the Rigifix© threaded sleeve.
Material:
Plug: Nylon.
Sleeve: High quality carbon machine steel.
Finish:
Zinc yellow passivated coated for protection.
Sizes:
M6 & M8 threaded set screw fixing.
INT: RIGIFIXM#
